Precision Index Rotary Table Series

Contact Us

See Now

Video

Watch
  • Way of revolving : Positive or negative rotation
  • No. Of Division: 1 °or 5 °
  • Longitudinal:Pneu. pressure 5~8kg.cm²
Parameter
Model Table Size(mm) Height(mm) Max. Load Weight(kg) Flux Penetration(mm) Pole Size (mm)
PIT-450 450*450 170 2000
PIT-450C 450*450 170 2000 15 70*70
PIT-600 600*600 205 3000
PIT-600C 600*600 205 3000 15 52*52
PIT-800 800*800 265 4000
PIT-800C 800*800 265 4000 15 70*70
PIT-1000 1000*1000 265 5000
PIT-1000C 1000*1000 265 5000 15 70*70
PIT-1200 1200*1200 265 10000
PIT-1200C 1200*1200 265 10000 15 70*70
PIT-1500 1500*1500 340 12000
PIT-1500C 1500*1500 340 12000 15 70*70
  •
  •
